RTE15

All-terrain electric pallet truck 1500 kg

RTE15

All-terrain electric pallet truck 1500 kg

The RTE15 all-terrain electric pallet truck handles loads of up to 1500 kg on rough ground such as construction sites or agricultural environments. Its large wheels and increased ground clearance ensure stable travel and obstacle clearance on uneven surfaces.

more information

	Designation
	RTE15 All-terrain electric pallet truck 1500 kg, lithium 48 V / 85 Ah Weight : 640 kg Bar code : 3700664815060

DESCRIPTION

TECHNICAL CHARACTERISTICS

The RTE15 all-terrain electric pallet truck is designed for pallet handling in environments where a standard pallet truck quickly loses efficiency due to uneven ground or outdoor conditions. With a rated capacity of 1.5 tonnes, its design meets the constraints of outdoor use and degraded surfaces.

This professional material handling equipment provides a powered load transport solution for agricultural areas, construction sites and mixed-use locations combining concrete slabs, gravel, stabilised tracks or irregular ground.

It is particularly suitable for load handling on construction sites, agricultural premises, outdoor storage areas and building material platforms.

Mobility adapted to demanding terrain

This professional pallet truck is fitted with large wheels and high-traction solid tyres, combined with a ground clearance of 130 mm. The RTE15 electric pallet truck therefore covers the need to move palletised loads where the use of a forklift truck is limited by space, ground conditions or internal flow organization.

The RTE15 all-terrain pallet truck is well suited to areas where internal logistics require frequent movements without the guarantee of perfectly smooth flooring. Agricultural yards, outdoor storage areas, site welfare facilities, material platforms or preparation zones close to loading bays are typical examples. The RTE15 ensures the link between a storage area and a loading point, or between several buildings, when surface conditions vary along the route.

In logistics operations, this type of equipment reduces reliance on larger machines such as forklift trucks when the task is limited to transferring a pallet over short to medium distances. Pedestrian operation makes integration easier in confined spaces, while maintaining obstacle-crossing capability suited to common outdoor ground irregularities.

Advantages of the RTE15 all-terrain electric pallet truck

The RTE15 is designed to provide more consistent powered handling on difficult terrain, with a level of safety and control compatible with site requirements.
Adapted obstacle clearance on uneven ground: large wheels, high-traction solid tyres and 130 mm ground clearance to maintain mobility on degraded surfaces.
Controlled traction: PMSM drive motor and speed control for smoother, more consistent travel with or without load.
Manoeuvrability in congested areas: compact design, 1320 mm turning radius and improved visibility thanks to rear-mounted battery.
Protection in demanding environments: reinforced structure and protected components for increased resistance to impacts and site conditions.
Simplified charging: integrated charger for recharging from a standard power socket, without the need for an external charger.
Operational safety: electromagnetic service brake, manual parking brake and signal lights to improve visibility.
Fork area versatility: standard fork carriage and high-strength forged forks, with options for different fork lengths and accessories depending on configuration.

Technical specifications of the RTE15 all-terrain electric pallet truck
Structure / chassis / load capacity
The RTE15 electric pallet truck handles a rated load of 1.5 tonnes with a 500 mm load centre, standard for pallet handling operations. Its wide, protective chassis shields sensitive components, reducing exposure to impacts in outdoor environments. The weight with battery is 640 kg, contributing to ground stability during travel. The standard lift height of 300 mm meets transfer and light obstacle clearance requirements without the need for stacking.
Travel speed and gradients
Travel speed reaches 4.6 km/h with load and 4.8 km/h without load, suitable for controlled movement in mixed-use areas. Gradeability reaches 18% with load and 20% without load, providing useful margin on ramps, site access points or moderate level changes. The electromagnetic service brake improves stopping control and overall travel safety.
Manoeuvrability and dimensions
Overall dimensions make this pallet truck suitable for restricted access areas: overall length 1667 mm and width 1598 mm. The 1320 mm turning radius facilitates turning and repositioning. The aisle width with an 800 × 1200 mm pallet lengthways is 1984 mm, allowing integration into many professional environments. Tiller height ranges from 780 to 1246 mm, supporting comfortable pedestrian operation on uneven ground.
Wheels and running gear
Running gear is central to the all-terrain concept. The drive wheel measures 300 mm in diameter and 90 mm in width, while the front load rollers reach 323 mm by 100 mm. These dimensions help overcome surface irregularities and reduce blockages on degraded ground. Polyurethane wheels and solid tyres enhance resistance to debris and puncture risks in construction environments.
Power, drive system and autonomy
Traction is provided by a 1.5 kW motor (S2 60 min) and lifting by a 1.2 kW motor (S3 10%). Power is supplied by a 48 V / 85 Ah battery. The integrated charger allows recharging close to the operating area, subject to access to a standard power outlet. Noise level remains below 70 dB(A), supporting daily use where acoustic comfort is important, including semi-enclosed sites.

Ergonomics, MSD prevention and safety

Motorisation reduces the physical effort associated with manual pulling, limiting repetitive strain on shoulders, back and upper limbs. Pedestrian operation maintains direct control of travel, particularly useful on uneven ground where trajectory and speed require precision. Visibility is enhanced by the compact design and rear battery positioning, improving fork area awareness during pallet approach.

In terms of safety, the electromagnetic service brake secures stopping phases, while the manual parking brake stabilizes the truck when stationary. Signal lights improve visibility in shared traffic areas. Protected components and a reinforced structure limit damage from impacts, reducing the risk of operational incidents.

Productivity and operational benefits

Daily productivity depends on consistent movement and minimal interruptions. The RTE15 reduces the typical blockages encountered with standard pallet trucks when floors include defects, gravel or unfinished areas. Integrated charging simplifies energy management close to work zones, avoiding dedicated travel to technical charging areas.

Compatibility with different fork configurations and selected accessories allows the equipment to be adapted to site-specific constraints. This approach reduces machine changes and supports continuity of internal flows, particularly on construction sites or agricultural operations where requirements evolve over time.

The RTE15 combines the expected functions of an electric pallet truck with a clear reinforcement of all-terrain capability. Its 1500 kg capacity covers standard pallet handling applications. Large wheels, 130 mm ground clearance and PMSM traction define its off-road performance. Compact design, braking systems and signaling support safer operation, while the integrated charger simplifies energy management.

Overall, it provides a coherent solution for organizations seeking powered pallet transfer without moving to heavier equipment.

Typical applications for the RTE15 all-terrain electric pallet truck
Supplying production areas from outdoor storage zones
Moving pallets between buildings across uneven yards
Handling materials, consumables and pallets on construction sites
Agricultural logistics between sheds, workshops and loading areas
Pallet transfers on platforms requiring travel over gravel or stabilized surfaces

Who is this all-terrain electric pallet truck for?

The RTE15 is suited to professional environments combining pallet handling with ground constraints: construction companies, agricultural operations, public authorities with outdoor depots, building material merchants, maintenance platforms and industrial sites with unfinished peripheral areas. It also meets the needs of logistics teams looking for an all-terrain electric pallet truck capable of moving pallets up to 1500 kg on uneven ground, with a level of control compatible with on-site traffic.

This equipment is suitable if you are looking for:
An all-terrain electric pallet truck for construction site use
A 1500 kg pallet truck for uneven outdoor surfaces
An electric pallet truck for agricultural operations and farmyards
An all-terrain pallet truck with high-traction solid tyres
An electric pallet truck with increased ground clearance
A compact pedestrian pallet truck for difficult access areas
An electric pallet truck with integrated charger and standard socket
An all-terrain pallet truck for pallet transfer between buildings and loading bays
A robust electric pallet truck for demanding construction environments
A pallet truck for standard pallets, widthways or lengthways handling

The RTE15 provides a powered pallet handling solution where ground conditions limit the use of a conventional pallet truck. To confirm suitability for your application (pallet type, ground conditions, ramps, accessories, traffic constraints), the STOCKMAN team is available to help define the most appropriate configuration based on internal flows and operating conditions. Contact details for your local STOCKMAN sales representative are available on our contact page.
