PRS-200

Stand-on/lean-on high-speed ride-on electric pallet truck 2000 kg

PRS-200

Stand-on/lean-on high-speed ride-on electric pallet truck 2000 kg

The PRS-200 lithium ride-on electric pallet truck handles loads of up to 2000 kg in intensive operations. Designed for logistics warehouses, it features a suspended platform and a secure stand-on/lean-on driving position for controlled, high-frequency internal transport.

more information

	Designation
	PRS-200 High-speed rider electric pallet truck 2T lithium 24V/150Ah 1190 x 540 mm Weight : 1110 kg Bar code : 3700664814537

DESCRIPTION

TECHNICAL CHARACTERISTICS

The PRS-200 is a lithium ride-on electric pallet truck designed for internal material handling, with a rated capacity of 2000 kg. It plays a key role in logistics organisations that require fast, repeated and continuous pallet movements throughout the working day.
Within the STOCKMAN range, it meets the need for powered traction with a ride-on operator position, reducing walking, improving comfort and securing internal movements. The PRS-200 combines a 24 V / 150 Ah lithium battery with an operator-oriented design, including a suspended platform and adjustable driving position.
This configuration is intended to provide stable driving, precise control and reliable performance in intensive duty cycles.

A high-speed electric pallet truck with stand-on/lean-on driving position, ideal for logistics warehouses

The PRS-200 is used in warehouses, logistics platforms, industrial storage areas, distribution backrooms and order picking zones. It is particularly suited to medium-to-long distance routes where internal flows require frequent shuttles between receiving, picking, repacking and dispatch.

In professional environments, a ride-on pallet truck helps structure internal movements while reducing breaks in work rhythm. It supports operational continuity on main aisles and transfer zones. Its compact design allows easy integration into existing layouts while maintaining a 2-tonne capacity suitable for most standard pallets.

Speed settings and secure access via PIN code or RFID badge ensure consistent adaptation to site constraints and operator experience levels.

Benefits of the PRS-200 high-speed electric pallet truck

The PRS-200 enables smoother, more comfortable and better-controlled powered handling:
2000 kg capacity: transfer of heavy pallets in daily flows without operational disruption.
24 V / 150 Ah lithium battery: energy suitable for intensive use, with simplified management compared to traditional batteries.
Configurable driving parameters: PIN/RFID access and distinct speed modes to manage internal traffic according to zones.
Suspended platform: shock absorption and reduced vibration on uneven floors, with thick rubber mat.
Adjustable operator station: electrically adjustable backrest, adjustable seat angle and adjustable armrest for improved stability.
Operational safety: OPC pedal and warning light to enhance control in shared areas.
Easy maintenance: accessible components and programming port for diagnostics, with on-screen status and error codes.

Technical characteristics of the PRS-200 electric pallet truck
Structure / platform / chassis / load The PRS-200 features a ride-on configuration with an integrated platform, reducing walking and stabilising posture on repetitive routes. Rated capacity is 2 tonnes with a 600 mm load centre, suitable for standard pallets. Standard lift height is 125 mm, with a minimum fork height of 85 mm for easy pallet entry. Fork length of 1150 mm and outer width of 540 mm match standard formats, limiting the need for adaptation.
Speed and travel Travel speed reaches 12 km/h unloaded and 10 km/h loaded. Three driving modes structure operation:
E (ECO): default limit 6 km/h
S (Standard): default limit 10 km/h
H (High performance): up to 12 km/h These modes balance safety in constrained areas and productivity over long distances. An electromagnetic service brake ensures controlled stopping during operation.
Manoeuvrability and dimensions
With an overall width of 790 mm and a turning radius of 1807 mm, the PRS-200 offers a balance between compactness and stability. Aisle width with a 800 × 1200 mm pallet is 2471 mm, a useful indicator for warehouse integration. The steering system includes a damper and programmable speed reduction according to steering angle, improving cornering stability and reducing jolts during direction changes.
Wheels and travel
Polyurethane wheels are suited to industrial floors. The drive wheel (Ø250 × 80 mm) and front rollers (Ø82 × 70 mm) ensure smooth travel. A twin support wheel (Ø150 × 54 mm) on the same axle stabilises operation on uneven floors and limits wear from counter-rotation. Adjustable side wheels help maintain level travel. Fork rollers are available in single or tandem configuration depending on pallet type, with lateral protection against material wrapping.
Power, motors and autonomy
The 24 V / 150 Ah lithium battery is the core energy source of the PRS-200. The traction motor delivers 2.5 kW (S2 60 min), while the lift motor delivers 2.2 kW (S3 10%). The LCD display provides key operating information: speed, battery charge level, active mode, electrical system status and operating hours.

Energy consumption according to the VDI cycle is rated at 0.4 kWh/h, supporting a rational approach to operating costs. Noise level at the operator position remains below 69 dB(A), contributing to comfort during extended use.

Ergonomics, MSD prevention and safety

The PRS-200 aims to reduce physical strain through motorised handling and a ride-on driving position. The suspended platform absorbs shocks caused by floor imperfections, while the anti-vibration mat limits vibration transmission to the operator.

The adjustable backrest and seat settings promote a more stable posture during repetitive travel. The adjustable armrest improves upper-body support and steering control. From a safety perspective, the OPC pedal requires operator presence and helps keep feet within the designated area.

A warning light signals the pallet truck’s presence in shared work zones. Thumb-operated joystick control centralises driving, lifting and lowering functions, reducing dispersed movements and promoting more controlled operation.

Productivity and operational efficiency

In warehouses, productivity depends on consistent internal flow rates. The PRS-200 offers travel speeds suited to long distances and driving settings that structure circulation according to zones. E, S and H modes support a safety-focused policy while maintaining high performance in large areas. PIN code or RFID badge access limits unauthorised use and ensures consistent parameter settings.

Maintenance benefits from easy component access and a programming port, reducing downtime during diagnostics. On-screen display of system status and error codes supports faster troubleshooting and return to service.

he PRS-200 is a 2000 kg lithium ride-on electric pallet truck suited to sites seeking compact equipment, high travel speed and operator comfort. Its suspended platform, adjustable operator station and OPC safety features enhance control on repetitive routes. The 24 V / 150 Ah lithium battery, LCD display and PIN/RFID access support stable, structured daily operation.

Typical applications of the PRS-200 stand-on electric pallet truck

The PRS-200 integrates into practical internal handling tasks such as:
Transfers from receiving to storage on standard pallets
Shuttles between order picking and dispatch consolidation
Feeding production lines or zones with pallets and palletised bins
Moving heavy pallets over long distances in logistics platforms
Travel on main aisles with speed management via driving modes
Daily handling in mixed-use areas requiring visual signalling Target companies and sectors

The PRS-200 is designed for organisations seeking a ride-on pallet truck to intensify internal flows while reducing walking distances. It is suited to logistics platforms, distribution warehouses, industrial sites and material handling service providers looking for a 2000 kg lithium ride-on electric pallet truck for regular duty cycles.

It also meets the needs of sites requiring controlled operation via PIN code or RFID badge, and improved operator comfort over repeated routes.
