Standard manual hitch for electric tow tractor

565438010007

Standard manual hitch for electric tow tractor

Standard manual hitch for connecting a wheeled load to a compatible electric tow tractor TE10LI (standard), TE20LI (optionnal), TE30LI (optionnal). Adjustable plate height from 25 to 60 mm and spring-pin locking.Must be ordered together with drawbar arm part number 568598510006.

more information

	Designation
	565438010007 Manual tow-tractor hitch, 25 to 60 mm adjustment, spring-pin locking Weight : 2 kg
	568598510006 Height-adjustable tow-tractor arm, centring spring, 60 x 60 mm mounting flange Weight : 3 kg

DESCRIPTION

TECHNICAL CHARACTERISTICS

The STOCKMAN 565438010007 standard manual tow hitch connects a wheeled load to a compatible electric tow tractor. Featuring an adjustable plate with a 25 to 60 mm setting range and a spring-loaded locking pin, this accessory provides a mechanical connection between the tractor and the equipment being moved. It is intended for in-house towing of carts, trailers and other wheeled loads with a suitable coupling point.

A mechanical connection for moving wheeled loads

In warehouses, workshops and logistics areas, electric tow tractors move wheeled equipment without requiring operators to pull the load manually.

The 565438010007 hitch provides the connection point between the tractor and the towed equipment. Its manual coupling system allows a compatible wheeled load to be attached before moving off.

The hitch configuration must be checked against the drawbar or coupling device fitted to the load to ensure a suitable mechanical connection.

Adjustable plate and spring-loaded pin locking

The hitch plate has an adjustment range of 25 to 60 mm. This enables the plate position to be adapted to the characteristics of the intended coupling interface.

The spring-loaded locking pin secures the mechanical coupling once engaged. The operator must check that the pin is properly seated before moving the load.

This design is suitable for applications involving the manual connection and disconnection of different wheeled items, provided they are compatible with the hitch.

Which electric tow tractors can accommodate this hitch?

This accessory is listed for the following STOCKMAN electric tow tractors:
TE10LI: electric tow tractor with a rated towing capacity of 1 000 kg.
TE20LI: electric tow tractor with a rated towing capacity of 2 000 kg.
TE30LI: electric tow tractor with a rated towing capacity of 3 000 kg.

These capacities refer to the respective tractors and do not constitute a rated capacity for the hitch itself. The towed load must comply with the tractor specifications and the coupling conditions.

Applications in workshops and logistics areas
Connecting a wheeled cart to an electric tow tractor.
Towing compatible trailers in a warehouse.
Moving handling carts between workstations.
Connecting a TE tractor to a wheeled load in a workshop.
In-house transport of equipment on carts fitted with an appropriate hitch point.
Manual connection of wheeled equipment in technical departments and logistics operations.

Checking the hitch before use

Before each towing operation, the operator must check that the hitch is securely attached to the tractor, inspect the spring-loaded pin and verify that the wheeled load's coupling point is compatible.

Operation must also comply with the towing limits of the tractor, the characteristics of the towed cart and the intended traffic conditions.

Technical specifications of reference 565438010007
Description: standard manual hitch for an electric tow tractor.
STOCKMAN reference: 565438010007.
Plate adjustment: 25 to 60 mm.
Locking mechanism: spring-loaded pin.
Coupling: manual mechanical connection.
Listed compatible tractors: TE10LI, TE20LI and TE30LI.
Stated weight: 2 kg.

Frequently asked questions about the 565438010007 manual hitch

What is a manual hitch used for on an electric tow tractor?
It mechanically connects a compatible wheeled load to the tractor so the load can be moved by towing.

Which STOCKMAN tractors can use this accessory?
The reference is associated with the TE10LI, TE20LI and TE30LI electric tow tractors in the STOCKMAN product range.

How does the locking mechanism work?
The coupling uses a spring-loaded pin. Its correct engagement must be checked before each movement.

Can any wheeled cart be connected?
No. The cart's coupling device must be mechanically compatible with the hitch. Dimensions and towing conditions must be checked beforehand.

Check the compatibility of your wheeled equipment

To choose a suitable hitch for your TE10LI, TE20LI or TE30LI tractor and check the connection interface of the wheeled load, contact your local STOCKMAN sales representative. You will find their details on our contact page.
