SCP750DBR

SCP750DBR Electric Counterbalanced Workshop Crane with 270° Rotation, Electric Lift and Reach, Remote Control 750 kg

SCP750DBR

SCP750DBR Electric Counterbalanced Workshop Crane with 270° Rotation, Electric Lift and Reach, Remote Control 750 kg

The SCP750DBR electric mobile crane lifts loads up to 750 kg and provides 270° mast rotation for handling in confined workshop areas. Its electric double jib and remote control ensure safe and precise positioning for internal industrial lifting operations.

more information

	Designation
	SCP750DBR Motorised cantilever workshop crane, 220° rotation, electric lift/extension, remote control, 750 kg Weight : 1300 kg Bar code : 3700664814094

DESCRIPTION

TECHNICAL CHARACTERISTICS

The SCP750DBR motorised counterbalanced mobile crane belongs to the range of electric workshop cranes designed for internal handling in industrial environments.

Its maximum lifting capacity reaches 750 kg. The cantilever design, combined with an electrically controlled telescopic jib, is suited to lifting operations requiring clear access to the load and precise positioning at the workstation. Within the STOCKMAN range, this equipment provides a mobile lifting solution that eliminates the constraints of fixed installations.

The 270° rotating mast and remote control operation enhance manoeuvre control when working in confined or restricted areas.

A cantilever workshop crane with rotating mast, ideal for production, maintenance and assembly areas

The SCP750DBR is well suited to production workshops, maintenance zones, machining cells and assembly areas where internal flows require short and repeated movements.

Its mobility supports organisations that alternate between several workstations during the same day: moving a component from a pallet, positioning it on a bench, removing it after testing, then transferring it to a storage area.

In workshops with high co-activity, a compact crane reduces floor congestion while maintaining usable traffic lanes. The 270° mast rotation allows load orientation without systematically repositioning the chassis, improving workflow continuity in confined environments.

Benefits of the SCP750DBR cantilever workshop crane with rotating mast

This electric mobile crane is designed for controlled handling of heavy loads close to workstations. Operational benefits focus on control, safety and precision.
270° rotation: load orientation without repeated chassis movements, reducing manoeuvres in narrow aisles.
Cantilever reach up to 2400 mm: improved access over common workshop obstacles such as machine frames or guarding.
Electric double jib: progressive adjustment of lifting geometry for sensitive components.
Remote control operation: remote handset with variable speed enables fine control during millimetre-accurate positioning.
Integrated signalling and safety features: LED signal tower, emergency stop and overload protection contribute to safer operation.

Technical characteristics of the SCP750DBR cantilever workshop crane with rotating mast
Structure / platform / chassis / load
The crane is built on a compact chassis with integrated counterweight, allowing lifting operations without external stabilisers. This architecture improves equipment availability across different workstations, as no additional legs or supports are required before lifting. The cantilever design facilitates access close to machines and frames, with a swivel hook that follows the natural orientation of the sling during placement.
Travel speed and movement
Travel control is managed via an ergonomic tiller with fast or slow speed selection. This meets two distinct needs: steady travel between workstations and slow, controlled approach in the work area. The push-button remote control with potentiometer adjustment enhances progressive movement, particularly useful when positioning motors, tooling or mechanical sub-assemblies.
Manoeuvrability and dimensions
Compactness is a key criterion for a mobile workshop crane. The stated width of 990 mm allows passage through technical aisles or between assembly stations. The bearing-mounted rotating turret, combined with manual indexed locking, stabilises mast orientation in predefined positions and limits unwanted movement when handling suspended loads.
Wheels and rolling
The wheels are designed for movement on industrial floors. Travel under load remains subject to safety rules and load charts, but the design supports internal transfers on flat surfaces with precise approach enabled by variable speed control. Forklift pockets allow handling of the crane itself during internal relocation or workshop reconfiguration.
Power supply, drive system and autonomy
The crane operates on sealed AGM batteries, with an optional lithium battery configuration. This solution suits indoor environments thanks to quiet, emission-free operation. A display provides operating data such as running hours, real-time battery voltage and charge level percentage. The charging connector and compatibility with an external charger support simple recharging routines suitable for daily use.

Ergonomics, MSD prevention and safety

The SCP750DBR helps reduce physical strain associated with manual handling of heavy loads. Motorisation eliminates the pulling and pushing forces typical of non-motorised cranes during internal movement. The ergonomic tiller, combined with speed management, improves control during approach phases and reduces repetitive corrective actions at the workstation.

Safety is ensured through multiple devices: emergency stop button, LED signal tower with operating status and overload indication, as well as overload and uncontrolled descent protection. Productivity and operational efficiency An electric mobile crane supports continuous operational flow. The benefit extends beyond lifting alone to the entire internal logistics process. Mobility allows the lifting device to be brought directly to the workstation, then the load to be moved without interrupting workflow.

The 270° rotation reduces chassis repositioning, limiting downtime during placement on tables, benches or machines. Battery status and operating hour displays assist with recharge scheduling and preventive maintenance planning, reducing the risk of unexpected downtime and stabilising daily handling operations.

The SCP750DBR motorised cantilever mobile crane combines a 750 kg capacity with a design focused on precision and control. The electric double jib, cantilever reach up to 2400 mm and 270° rotation address lifting needs close to machines and in restricted-access areas. Travel and lifting controls prioritise progressive movement, while safety and signalling systems support controlled industrial handling.

Typical applications of the SCP750DBR cantilever workshop crane with rotating mast

This crane integrates into internal handling scenarios requiring precision and mobility:
Equipment maintenance and removal of mechanical assemblies
Tool changes and component positioning on CNC machines
Feeding test benches and positioning sensitive parts
Handling on assembly lines and assembly workstations
Lifting loads in areas difficult to access with a standard workshop crane

Who is the SCP750DBR cantilever workshop crane for?

The SCP750DBR is designed for workshops and technical departments seeking a 750 kg electric mobile crane for repeated operations requiring rotation and reach.

It meets the needs of production, maintenance and tooling environments that demand precise positioning, speed control and reduced physical strain.

Target users include industrial facilities, mechanical workshops, aerospace operations, line integrators, as well as testing and machining specialists.

This product meets the needs of users looking for:
A 750 kg electric mobile crane for workshop handling
A compact cantilever crane for confined production areas
A 270° rotating crane for precise load positioning
A counterbalanced mobile crane without fixed installation
A workshop crane with remote control for controlled manoeuvres
A mobile crane for tool changes on CNC machines
A lifting crane for industrial maintenance and component dismantling
A quiet electric mobile crane for indoor environments
A cantilever crane for assembly lines and workstations
A mobile crane for test benches and sensitive component handling

The SCP750DBR motorised cantilever mobile crane provides an internal lifting solution combining mobility, precision and safety, with a maximum capacity of 750 kg. Final suitability must be validated using the load chart based on reach and lifting height.

The STOCKMAN team supports configuration definition, particularly regarding AGM or lithium battery selection and compatible lifting accessories.
